LHVCX800/1000/1250/1400 Vacuum contactor
(VC for wind and solar power)
|
|
|
|
Working voltage |
LHVCX800 |
LHVCX1000 |
LHVCX1250 |
LHVCX1400 |
AC-1 |
|
|
|
|
|
-25/+40° |
1000v |
1100A |
1200A |
1300A |
1400A |
-25/+60° |
850A |
1000A |
1000A |
1000A |
|
|
|
|
|
|
-25/+40° |
690V |
1100A |
1200A |
1300A |
1400A |
-25/+60° |
850A |
1000A |
1200A |
1400A |
AC-3 |
|
|
|
|
|
-25/+40° |
1000V |
435A |
580A |
750A |
820A |
690V |
650A |
820A |
1000A |
1000A |
Rated impulse withstand voltage |
|
8000V |
8000V |
8000V |
8000V |
Rated power frequency withstand voltage |
Vacuum break |
5000V |
5000V |
5000V |
5000V |
Phase to phase and to earth |
4200V |
4200V |
4200V |
4200V |
Rated insulation voltage |
|
1000V |
1000V |
1000V |
1000V |
Rated working voltage |
|
1000V |
1000V |
1000V |
1000V |
Rated breaking capacity |
1000V |
5800A |
5800A |
5800A |
5800A |
690V |
8200A |
8200A |
8200A |
8200A |
Rated making capacity |
1000V |
7800A |
7800A |
7800A |
7800A |
690V |
10000A |
10000A |
10000A |
10000A |
Pollution degree |
|
3 |
Overvoltage category |
|
Ⅲ |
control circuitvoltage |
|
220V |
Electrical life |
|
100,000 times |
Mechanical life |
|
300,000 times |
|
| |
|
|
| |
|
| |
|
